What is Linearity Study in Medical Laboratory?
Published 29 Jul 2026
A linearity study in a medical laboratory is a method validation and verification procedure used to determine whether a test method produces results that are directly proportional to the concentration of an analyte across its claimed measuring range.
In simple terms:
If the concentration doubles, the test result should also double (within acceptable limits).
Linearity is an essential performance characteristic required during method validation, verification, and quality assurance, especially under standards such as ISO 15189:2022 and guidelines like CLSI EP06.
Why is a Linearity Study Important?
A linearity study helps ensure that:
Results are accurate across the entire analytical measuring range (AMR).
Patient reports remain reliable at low, normal, and high concentrations.
Instruments perform consistently.
Calibration is valid throughout the measuring range.
The laboratory complies with accreditation requirements (ISO 15189, NABL).
Example of Linearity
Suppose a glucose analyzer claims to measure from 20 mg/dL to 600 mg/dL.
Prepare samples at different concentrations:
| Expected (mg/dL) | Measured (mg/dL) | Bias (mg/dL) | % Bias |
|---|---|---|---|
| 20 | 21 | +1 | +5.00% |
| 100 | 99 | -1 | -1.00% |
| 200 | 201 | +1 | +0.50% |
| 300 | 299 | -1 | -0.33% |
| 400 | 402 | +2 | +0.50% |
| 500 | 498 | -2 | -0.40% |
| 600 | 601 | +1 | +0.17% |
Linearity Data Visualization
Interpretation
The measured values closely match the expected values across the entire analytical range (20–600 mg/dL).
The maximum deviation is only ±2 mg/dL, indicating excellent agreement.
The percentage bias ranges from -1.00% to +5.00%; the largest percentage bias occurs at the lowest concentration (20 mg/dL), which is common because small absolute differences appear larger in percentage terms.
Overall, this dataset demonstrates excellent linearity and would typically be expected to produce an R² value greater than 0.999 in a linear regression analysis.
When Should a Linearity Study Be Performed?
Perform a linearity study when:
Introducing a new analyzer.
Installing a new test method.
Changing reagent lots (if required by the manufacturer or laboratory policy).
During method validation or verification.
After major instrument maintenance (when indicated).
As required by laboratory quality management procedures.
Materials Required
High-concentration sample or calibrator
Low-concentration sample or diluent
Certified reference materials (if available)
Micropipettes
Analyzer
Quality control materials
How to Perform a Linearity Study
Step 1: Select High and Low Samples
Choose one sample with a high analyte concentration and one with a low or near-zero concentration.
Step 2: Prepare Serial Dilutions
Prepare 5–11 concentration levels by mixing the high and low samples in different proportions.
Example:
| Level | High Sample | Low Sample |
|---|---|---|
| L1 | 100% | 0% |
| L2 | 80% | 20% |
| L3 | 60% | 40% |
| L4 | 40% | 60% |
| L5 | 20% | 80% |
| L6 | 0% | 100% |
Step 3: Test Each Level
Analyze each dilution according to the laboratory protocol, preferably in duplicate or triplicate to improve reliability.
Step 4: Record the Results
Create a worksheet containing:
Expected concentration
Measured concentration
Difference (Bias)
Percent recovery
Step 5: Analyze the Data
Evaluate:
Scatter plot of expected vs. measured values
Regression equation
Correlation coefficient (R²)
Percent recovery
Bias at each concentration
Generally, an R² value close to 1.000 indicates excellent linearity, but acceptance should also consider bias and clinically acceptable error.
Acceptance Criteria
Acceptance criteria should be based on:
Manufacturer recommendations
Laboratory-defined limits
Biological variation (where applicable)
Regulatory or accreditation requirements
Common evaluation parameters include:
Acceptable percent recovery
Acceptable bias
Linear regression fit
No clinically significant non-linearity
Common Causes of Poor Linearity
Incorrect calibration
Pipetting errors
Reagent deterioration
Instrument malfunction
Matrix effects
Sample preparation errors
Incorrect dilution technique
Benefits of a Linearity Study
Improves patient result accuracy
Confirms the analytical measuring range
Detects analytical errors early
Supports ISO 15189 and NABL compliance
Increases confidence in laboratory reports
Demonstrates instrument performance
Difference Between Linearity and Accuracy
| Linearity | Accuracy |
|---|---|
| Evaluates proportionality across the measuring range | Evaluates closeness to the true value |
| Uses multiple concentration levels | Uses reference or target values |
| Assesses method performance over a range | Assesses correctness of individual measurements |
Relevant Guidelines
ISO 15189:2022 – Medical laboratories: Requirements for quality and competence
CLSI EP06 – Evaluation of Linearity of Quantitative Measurement Procedures
Manufacturer - specific validation recommendations
